Edvantest Measure Technologies Private Limited

Special Features
• AmpTip ™ low-current range calibrated at Jaw-tip for slim-conditions for accurate readings
•  MAX/MIN/AVG Recording mode (Auto ranging)
•  VFD-V & Hz for fundamental V/Hz of most Variable-Frequency-Drives
•  Display Hold & Non-Contact EF-Detection (NCV)
•  Back-lighted easy-to-read LCD display
•  Back-lighted easy-to-read LCD display
•  BackFlashlight for easy operation in dim areas
•  BackFast 80ms Peak-RMS mode to capture in-rush currents
•  BackAuto-ranging Relative mode with DC-Zero mode &
•  Back5ms Crest (Instantaneous Peak-Hold) mode

MOTWANE's Digital Clamp Meter DCM-39A is a highly precision, Industrial grade, TRMS, auto ranging clamp meters with 3¾ Digit display. DCM-39A clamp meter can be used as Multimeter with test leads for AC/DC Current measurements upto 400 mA, AC/DC Voltage, resistance, Frequency, Capacitance, Duty Cycle and Diode, Continuity etc. This clamp meters is provided with safety features like Water resistance front panel, fireproof heavy-duty ABS casing. It uses a Hall Effect sensor for measuring the current.

The model DCM-39A measures AC/DC currents up to 1000A.

Features

• 0.1 mA Current Resolution.
• True RMS Measurement for all applications.
• LED Backlight function.
• MAX MIN measurement function.
• Data Hold function & Zero function.
• CAT IV 300V.
• Auto Power Off.
• Autoranging.

Features

• Overload protection on all ranges.
• Maximum Voltage between any terminal and earth ground 600V rms
• Dual slope integration
• Data-hold facility
• DCA zero button for accurate reading
• Low battery indication
• Auto power off

Special Features
• AmpTip ™ low-current range calibrated at Jaw-tip for slim-conditions for accurate readings
•  MAX/MIN/AVG Recording mode (Auto ranging)
•  VFD-V & Hz for fundamental V/Hz of most Variable-Frequency-Drives
•  Display Hold & Non-Contact EF-Detection (NCV)
•  Back-lighted easy-to-read LCD display
•  Fast 80ms Peak-RMS mode to capture in-rush currents
•  Auto-ranging Relative mode with DCZero mode & 5ms Crest
  (Instantaneous Peak-Hold) mode
•  3-Phase Rotation-R for MAINS supply (Probe contact)
•  3-Phase Rotation-M (Hi-sensitivity mode) for Motors (Probe-contact)

Features
• Industrial Grade Rugged Digital Multimeter
• Automatic Zero adjustment
• Peak Hold Function
• OverLoad Protection 500V DC or AC rms
• Auto range on Frequency range & measurement upto 2 MHz.
• Logic Test, Diode & Continuity Test & Transistor hFE Test.
• Low battery indication

The KM 071 Milliamp Process Clamp Meter is a Hand-held battery operated clamp meter that measures 4-20 mA DC without breaking the electrical circuit. Unlike conventional clamp meters, this meter features a small jaw that easy to reach any place there is a cable carrying with a current.. This meter takes a magnetic modulated technology, it can reach excellent sensitivity with great anti Earth Magnetical Field ability.

General Specifications
• Jaw Opening size : 5 mm max.
• DC mA measurement (4-20mA); 0-40mA
• Electronic Zero
• Percentage span (0-100%)
• Backlight display
• Measurement spotlight LED
• Data Hold
• Operating Temperature : -10 °C to 50 °C
• Storage Temperature : -25 °C to 70 °C
• Operating Humidity : < 90% @ < 30 °C, < 75% @ 30 to 50 °C
• Power Supply : 9V battery, IEC LR6
• Dimension : 59 (H) X 38 (W) X 212 (L) mm
• Weight : Approx. 260 gm ( battery included )

Special Features
* 600A AC Clamp-on + Multimeter ranges
* Ultra-slim jaws to access tight places
* Light weight & compact body to fit your hand
* Fully Auto-ranging for fast measurements
* Input Protection on all ranges
* Fast 30ms MAX Hold to capture in-rush currents
* Relative Zero mode
* Measures non-invasive ACA Frequency via clamp jaws
* Line level frequency measurements
* Data Hold function

General Specifications
• Sensing : Average sensing (KM 111M ); True RMS Sensing (KM 112M)
• Jaw Opening Size : 26mm
• Basic Accuracy : 0.5%
• Display : 3¾ Digits 4000 counts LCD display
• Update Rate : 3 per second nominal
• Polarity : Automatic
• Low Battery : Below approx. 2.4V.
• Operating Temperature: 0°C to 40°C.
• Relative Humidity: Maximum relative humidity 80% for temperature upto 31°C
  decreasing linearly to 50% relative humidity at 40°C
• Altitude : Operating below 2000m
• Storage Temperature : -20 °C ~ 60 °C,< 80% R.H. (With Battery removed)
• Temperature Coefficient : Nominal 0.15 x (specified accuracy) /
  °C @ (0 °C ~ 18 °C or 28 °C ~ 40 °C), or otherwise specified.
• Power Supply : Single 3V coin Battery IEC CR-2032.
• Power Consumption : 2.8 mA typical, except 3.3 mA typical for current function.
• APO Timing : Idle for 30 minutes.
• APO Consumption : 5 µA typical.
• Dimension : 190(L) x 63(W) x 32(H)mm
• Weight : Approx. 139gm

Features

Special Features

• AmpTip  low-current range calibrated at Jaw-tip for slim-conditions for accurate readings
• MAX/MIN/AVG Recording mode (Auto ranging)
• VFD-V & Hz for fundamental V/Hz of most Variable-Frequency-Drives
• Display Hold & Non-Contact EF-Detection (NCV)
• Back-lighted easy-to-read LCD display
• Fast 80ms Peak-RMS mode to capture in-rush currents
• Auto-ranging Relative mode with DC-Zero mode & 5ms Crest (Instantaneous Peak-Hold) mode.

• Thin, light, compact body design for one-hand operation
• 18mm triangular jaw allows for easy measurement on small cables
• Large, easy-to-read backlit display
• 200 A ac and dc current and 600 V ac and dc voltage measurement range
• 3000 Ω resistance range, continuity detection
• Zero function allows the display to be cleared for DC measurements
• Data Hold function
• CAT III 600 V safety rating

Features:

• 32mm jaw size, 2000 counts LCD display
• Low battery and overload indication
• Operating Temperature 0 Deg C to 50 Deg C
• Storage Temperature -20 Deg C to 60 Deg C
• Tough ABS plastic housing.
• Data Hold switch freezes reading
• Diode check
• Single 9V battery

Benefits:

• Ease to operate
• Safe and effective

You can measure around awkward sized conductors with the Fluke 376 True RMS Clamp Meter with iFlex®, expanding your measurement range to 2500 A AC. With True RMS voltage and current measurements, the Fluke 376 can read up to 1000 V and 1000 A in both AC and DC modes.

The Fluke 376 is the direct replacement for the Fluke 337 Clamp Meter.

Safety Conformance
EN/IEC 61010-1:2001; 1000V CAT III, 600V CAT IV

Special Features
• AutoCheck Voltage & Ohms
• VFD-V & VFD-HZ function
• 5ms CREST-MAX capture mode (Peak Hold)
• Autoranging Relative -Zero mode
• Display Hold function
• EF-Detection (NCV)
• Backlight LCD Display
• Auto Power Off
• Diode Test & Continuity Test
• PC Interface (Optional)

The Metravi PRO Solar-3 TRMS AC/DC Digital Clamp Meter is a professional  instrument  with TFT Colour Display, featuring fast A/D Converter and high accuracy.

Makes it easy to find and solve problems in production equipment with Trend Capture and helps with Bluetooth data transfer & analysis reports using free App on your Smartphone.
Ensures safe measurements with double-moulded plastic housing, IP65 waterproof certification, CATIV 600V, CATIII 1000V & CATII 1500V categorisation.

The Metravi Pro Solar-3 TRMS AC/DC Digital Clamp Meter measures upto 1500V DC measurement, and hence, is most suitable for Solar and Photovoltaic Applications. In-rush current, VFD and LoZ measurement functions make it a must for all Motor Applications too.
